Graphite thermal pad
Graphite sheets are high-performance thermal conductive materials made from polyimide (PI) or PET substrates through high-temperature carbonization and graphitization. They feature ultra-high thermal conductivity, low density, excellent flexibility, superior insulation, thin profile, lightweight design, and easy die-cutting. Ideal for smartphones, tablets, LED heat dissipation, new energy batteries, and more.
Material
Polyimide (PI)/PET + Graphitized Carbon Layer
Tolerance
Thickness tolerance: ±0.01mm; Thermal conductivity: 150-1500 W/m·K; Density: 1.5-2.2 g/cm³
Surface Treatment
Single-sided/double-sided adhesive, slitting and die-cutting, punching
Application Areas
Smartphone thermal management, tablet cooling, LED heat dissipation, new energy battery cooling, automotive electronics, communication equipment.
Product Features
- Ultra-high thermal conductivity (150-1500 W/m·K) with excellent heat dissipation.
- Low density and lightweight; adds no burden to the product.
- Flexible, bendable, and easy to fit
- Excellent electrical insulation with high breakdown voltage
- Slim design (thickness: 0.025-0.1mm) saves space
- Customizable size, shape, and thermal conductivity
